3 Axle 40ft Skeleton Semi Trailer for Sale

Skeleton semi trailers, also known as shipping container transport trailers, are mainly used for medium and long-distance transportation. They are generally suitable for the transportation of ISO containers such as ports, shipyards, routes, bridges, tunnels, transfer stations, etc., and are equipped with a multimodal logistics system. As a skeleton semi trailer manufacturer, we offer trailer options for transporting 20/40/45ft and other size skeleton semi trailer.

40ft Skeleton Semi Trailer Features

1. It is suitable for transporting bulk cargo with the characteristics of lightness, softness, low center of gravity, lightweight, high mass utilization rate, and strong bearing capacity.

2. Innovative design, tailor-made on the basis of fully understanding the analysis of the local traffic environment, drawing on advanced design concepts, and a number of innovations.

3. Advanced production technology and perfect testing equipment ensure that the overall structure of the product is reasonable and the performance is reliable.

4. Frame body Q345B high-strength steel structure, automatic submerged arc welding full beam, equal cross-section main longitudinal beam structure, to achieve the best bearing effect.

5. Well-known brand axle and suspension system, high performance and reliable use ensure the good performance of the whole vehicle.

6. The full braking and electrical system are in accordance with the ISO standards at home and abroad, and the ABS system is optional. The braking and lighting are absolutely safe and reliable.

7. The overall frame is sprayed with primer treatment, and the fine surface quality of paint spraying meets the maritime anti-corrosion standard.

details display.jpg

Parameter of 3 Axle 40ft Skeleton Semi Trailer

Dimension and Weight

Overall Dimension（mm）

12500x2500x1650mm

Wheelbase

7,500mm+1,310mm+1,310mm

Payload

40,000kg

Tare weight

6,500kg

G.V.W.R.

46,500kg

Function

transport 1x20ft, 2x20ft, 1x40ft container

Running System

Main beam

height of the beam is 500mm,

upper plate is 14mm,

down plat is 16mm,

middle plate is 8mm.

Side beam

16#

Axle

3x13Ton ZY brand

Axle Number

Three

Tire

12R22.5, 12 pcs. Taitong brand

Rim

9.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs

Suspension system

Mechanical Suspension

Steel Spring

10/10/10 leaf spring with 90mm(W) *13mm(thickness)

Electrical System

Chinese standard 24V lighting system

Brake system

Dual line pneumatic brake, no ABS

Brake air chamber

6 units T30/30 Double brake chambers

Emergency relay valve

Standard

Diamond plate

4mm

Traction/King Pin

2” and 3.5” removable Kingpin,

bolted in type 500mm from the front face of the front bolster

Landing Gear

Yahua brand 28ton

external two speed telescopic manual operation

2,500mm behind the kingpin location

Accessories

Tool box

1pcs, One crank and one shaft head wrench

Mud guard

Steel mud guard and front mudguard

Spare wheel carriers

2 pcs

Bumper

Rear bumper with adjustable height

Electrical system

1. Voltage: 24v   2. Receptacle: 7 ways (7 wire harness)

Tail lamp with turn signal, brake light & reflector, side lamp etc.

One set 6-core electric cable protected by PVC conduit on main frame

Paint

Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um,A layer of anti-rust paint,two-layer finish. Waxed

Packing

Nude, Polish with wax before shipping

Packing & Shipping

We have someone involved in monitoring your packaging and shipping process. Our experienced team will choose an economical and safe shipping method for you to ensure that the product is safely delivered to your hands.

packing & shipping.jpg

Our Services

1. Respond to your inquiry within 12 working hours;

2. Experienced staff to answer all your questions;

3. Customer's design can be used for some products (OEM);

4. All kinds of engine mechanical spare parts at a reasonable price;

5. Different kinds of semi-trailers can offer competitive prices.
