Side wall semi trailers are widely used for medium and long-distance transportation from light bulk cargo to heavy goods, containers, etc. Side wall semi trailers are widely used in transportation companies in the logistics industry. Durable, lightweight design with increased load-carrying capacity to accommodate current shipping constraints. Reasonable structure, reliable performance, and convenient use. The sidewall fence semi-trailer can be customized according to different carrying capacity requirements.
Application
Chengda sidewall semi trailers are your ideal partner for multi-purpose solutions for various applications including cement bags, agricultural bags, tiles, jumbo bags, steel coils, and more.
Parameter of side wall semi trailer
Dimension and Weight: |
Overall Dimension (Lx W x H)(mm) | 12500*2500*2550 |
Cargo box dimension (Lx W x H)(mm) | 12000X2300X600 |
Tare Weight(KG) | 6550 |
Loading Weight( KG) | 50000 |
Total Weight(KG) | 56350 |
Chassis and Running System: |
Axle Brand | 13Ton, Fuwa brand option one hundred fifty thousand Kilometers no need maintenance |
Axle Number | Three |
Wheelbase(mm) | 7450+1310+1310 |
Suspension system | Mechanical Leaf Spring Suspension |
Leaf spring | 90(W)mm*13(Thick)mm*10 Layer |
The material of Main beam | Q345B carbon steel,The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8 mm. |
Side beam | Q235 16# channel steel |
Platform plate | 3mm Diamond plate |
Tire | 12R22.5, 12 pcs. Taitong brand |
Rim | 9.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs |
Electrical System | Chinese standard 24V lighting system |
Brake system: | Dual line pneumatic brake, SAE hose and connector,no ABS |
Brake air chamber | 6 units T30/30 spring brake chambers |
Emergency relay valve | Wabco relay valve |
Traction/King Pin | 2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster |
Landing Gear | Zhenhua brand 28ton external two speed telescopic manual operation 2,500mm behind the kingpin location |
Accessories: |
Tool box | 1pcs, One crank and one shaft head wrench |
Mud guard | Steel mud guard and front mudguard |
Spare wheel carriers | 2 pcs |
bumper | Rear bumper with adjustable height |
Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
Tail lamp with turn signal, brake light & reflector, side lamp etc. |
One set 6-core electric cable protected by PVC conduit on main frame |
Paint | Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um,A layer of anti-rust paint,two-layer finish.Waxed |
Packing | Nude, Polish with wax before shipping |
Packaging and Shipping
Sidewall semi trailer transportation of unpacked goods: We recommend placing them in a 40ftHQ container, and container transportation can save a lot of freight. Of course, there are other shipping methods: Ro-Ro and Bulk Shipping.
FAQ
Does your company a factory or trade company?
We have a factory ourselves, we are on this business for 20 years in China.
What's the quality assurance we provide and how do we control quality?
Established a procedure to check products at all stages of the manufacturing process raw materials, process materials validated.
How do you transport the semi-trailers and trucks?
We transport the vehicle in bulk or container. Our factory possesses long-term cooperation with a shipping agency which can provide you lowest shipping fee.
Can you satisfy my special requirement?
Definitely! We are a direct manufacturer and have a strong production and R&D capacity!
