Features of Sinotruk Hohan 6X4 Prime Mover Truck
Buffering
The traction force can be smoothly transmitted to the trailer, which has a buffering effect on the impact load, and the connection with the trailer is reliable, convenient, and can be quickly disengaged.
Running smoothly
Avoid the idling of the driving wheels when the vehicle is driving on wet and slippery roads such as snow so that the vehicle can start and accelerate smoothly.
Reliable performance
Hohan 6X4 prime mover truck has good climbing performance and strong transportation capacity, which greatly saves time and labor, and shortens the transportation cycle.
Wide range of applications
As the main equipment for road transportation, it has the advantages of large loading capacity and fast transportation.
Application of Hohan Prime Mover Truck
It can carry different types of semi-trailers and is often used for the transportation of large quantities of goods, such as transportation from automobile manufacturing warehouses to assembly lines, and luggage transportation at airports.
Parameters of Hohan 6X4 Prime Mover Truck
| SINOTRUK HOHAN 6x4 Tractor Truck Specification |
| Model | ZZ4255N3246D1 |
| Traction | 6X4 |
| Driving type | LHD (RHD is option) |
| Cabin | H18 Cab, two seats, with two sleeper, with A/C; Equipped with Benz NG85 cab,Half round type aviation instrument desk with a large LCD display meter and relay control system;Hydraulically damped adjustable driver’s seat and rigid adjustable co-drivers seat with safety belts;Single berth with 4-point support fully floating suspension and shock absorber with transverse stabilizer;Electric glass elevator The manual door lock;Large, truck type convex 2 arm wind screen wiper system with 3 speeds;FM/AM/SW, 4 band radio/cassette recorder;Adjustable steering wheel |
| Vehicle Dimensions | LxWxH | 8150*2496*3720(mm) |
| Wheel base | 3600+1350(mm) |
| Wheel track | Front: 2022 Rear: 1830(mm) |
| App/Dep angle | 19/26(°) |
| Overhang | Front:1500 Rear:1720 |
| Weight in KGS | Dead Weight | 8250kg |
| Gross weight | 70000kg |
| Front axle capacity | 7000kg |
| Rear axle capacity | 2x16000kg |
| Driving Speed | 99 km/h |
| Engine | Brand: SINOTRUK |
| Model: WD615.47 371hp with Euro II Emission standard |
| Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter cooling |
| Displacement: 9.726L /Diesel |
| Max. Output: 273Kw@2200rpm according to DIN |
| Compression ratio: 17:1 |
| Bore/Stroke(mm): 126/130 |
| Fuel consumption: 195/kWh |
| Cooling System | Medium: Water with Twin cylinder air compressor |
| Radiator: heavy duty type |
| Cooling fan: VISCO static fan tropical type |
| Thermostat: Opening at 70-80℃ |
| Warning device: Audible & visual |
| Gear Box | SINOTRUK HW19710 Manual 10 Forward& 2 Reverse |
| Ratio:14.28 10.62 7.87 5.88 4.38 3.72 2.43 ... |
| Clutch | Single plate dry diaphragm spring clutch,Φ430 Diaphragm,hydraulically operating with air assistance |
| Steering | D50, hydraulic steering with power assistance; Ratio:22.2-26.2, 17.0-20.0 |
| Tyre | Tyre | 295/80R22.5 315/80R22.5 12R22.5 12.00R20 11.00R20 |
| No. of tyres | 10+1spare |
| Fuel Tank | 300L,with locking fuel cap, fitted to the off side of the chassis |
| Front Axle | HF 7, 7000kgs front axle with drum or disc brake |
| Rear Axle | ST16, 16tons double reduction driving axle, inter-wheel differential and differential lock |
| Frame | U-profile parallel ladder frame with section of 300×80×8mm,reinforced subframe,all cold riveted cross members |
| Suspension | Normal suspension |
| Brake System | Service brake | Dual circuit compressed air brake |
| Assistant brake | Engine exhaust valve brake |
| Parking brake | Spring energy, compressed air operating on rear wheels |
| Fifth Wheel | 90# or 50# |
Packaging and Transportation
By bulk: The cheapest way,put the truck on the deck of the ship.
By roro: The most protective way,put the truck in the ship cabin.
By flat rack container: one flat rack container can transport two tractor truck.
According to the type and volume of the goods, professional packaging and shipping methods will help customers save freight to the greatest extent.
