Foton GTL dump truck, drive mode 6X4, equipped with Foton Cummins X12 engine, maximum 460 horsepower engine, maximum torque 2300N.m. The transmission is a Fast 12-speed manual transmission.

MESSAGE

Foton 6X4 30Tons Dump Truck

Foton Foton 6X4 30Tons Dump Truck is mainly used in mining operations. The road conditions are harsh and the vehicle loading load is large, which puts forward higher requirements on the power performance of the engine.

Foton GTL dump trucks are mainly aimed at the heavy-duty market in the Auman product line. There are dump trucks and tractors, which are often strengthened with thickened and enlarged beams, wheel reduction bridges, and thick leaf springs, with reliable performance.

GTL DUMP TRUCK.jpg

Advantage of Foton 6X4 30Tons Dump Truck

1. Powerful and easy to climb

The Foton GTL dump truck is equipped with a high-horsepower engine, low-speed high-torque, and can easily cope with extreme road tests.

2. Strong reliability and more significant benefits

Foton Cummins engine inherits Cummins' century-old advanced engine manufacturing experience, the failure rate is reduced, and the operating profit efficiency is significantly improved.

Specification


foton GTL  dump truck detail.jpg

foton GTL  dump truck detail1.jpg

  Drive type  6×4
Complete  kerb mass (kg)11200
Max.speed (km/h)70
Min.turning circle(m)18
Min.ground clearance(mm)314
Approach / Departure angle (°)16/66
Max.gradeability(%)40
Appearance dimensions (mm)  Max.length  8275

  Max.width2490

Max.heigh3300
  Front / Rear overhang  1525/1600
Wheel base(mm)3800+1350
  Track width(mm)  1939 / 1800
Front axle 7.5tons
Rear axleShan Qi Steyr military reinforced axle 13tons
Gear ratio12.11 8.08 5.93 4.42 3.36 2.41 1.76 1.32 1.00 12.66R


Packaging & Shipping

ship dump truck


The transportation methods we can provide are: Ro-Ro, Bulk, and Containers.

We can provide customers with the most economical transportation solution according to the number and type of trucks required by customers.
