4 Axle End Dump Trailer for Sale

Chengda 4 axle U-shaped end dump trailers are used to transport bulk cargo, coal, ores, and construction materials. There is no dead angle in the corner of the U-shaped box, and the unloading is cleaner; Q345 high-strength carbon steel plate is used to reduce the tare weight; the damage to the box body by the mine head is reduced; the center of gravity of the U-shaped structure is low to avoid the overflow of goods. We use parts from world-famous brands, such as FUWA brand axle, Yahua brand Landing gear, and so on.

details display-1.jpg

details display.jpg

Appcation of 4 axle end dump trailer

4 axle end dump trailers are suitable for the transportation of bulk and bulk cargoes such as coal, ore, and construction materials.


Parameter of 4 axle end dump trailer

Detail specification


Model

4 axle end dump trailer


Function

Transport sand, stone, gravel

Dimension


Overall Size (L×W×H)mm

9800×2550×3860mm


Inner Size (L×W×H)mm

8500×2330×2000mm


Wheel base

6870+1310+1310mm

weight


Payload

68,000kg


Tare weight

Approx12,000kg


G.V.W.R.

Approx 80,000kg

Body details


Main beam

Material Q345 carbon steel, upper plate 18mm, down plate 18mm, middle plate 8+8mm.


Body thickness

6mm


Bottom thickness

8mm


Hydraulic System

Full set of HYVA Hydraulic System 202

Frame


Axle

heavy duty, 4×13Ton capacity, FUWA brand


Suspension

Leaf spring suspension, 90mm×16mm×10pcs


Tire

12R22.5 12units Chengda Brand


Kingpin

50mm/90mm removable


Landing gear

Yahua brand, 28ton, double speed, heavy duty


Tool box

1pcs


Spare wheel carrier

2pcs

Electrical system


Voltage

24Volt


Receptacle

7 way socket SAE standard,China


Front marker lamp

white


Side marker lamp

white&red


Rear lamp

red


Turn signal lamp

Amber


Wiring

Electric cable protected by PVC conduit on main frame

Brake system


Brake

Dual line pneumatic brake,SAE hose and connector,no ABS


Brake air chamber

Six big chamber


Painting

Shot blast at Standard SA 2.5 prior to application of primer,polyurethane top coat.Total DFT not less than 100um


Color

As customer requirement

About Us

We can also produce semi-trailers such as lowboy trailers, flatbed trailers, oil tanker trailers, bulk cement tank trailers, etc We are the manufacturer and provide customized service, designed to every requirement of customers. We have a professional trailer design department with rich production experience and a short delivery time. Our factory has passed ISO9001 quality system certification. Our telephone service is at your service 24 hours a day. Our cooperation can be in ODM or OEM mode.

factory display.png

We are the Cheng Da group, and we have exported to many countries, such as Zambia, Nigeria, Zimbabwe, and Senegal. We offer:

1. High-quality product.

2. Professional team.

3. Wealthy experience.

4.12 months quality warranty.

5.24 hours of service.

customer photos.jpg
