Beiben dump truck series have reliable structure, strong bearing capacity, strong power and reliable performance, which can meet your long-distance road transportation needs.

MESSAGE

BEIBEN 6x4 8x4 Dump Truck

2022 BEIBEN 6x4 8x4 dump truck is the latest generation of dump trucks newly built using Beiben's cutting-edge weight reduction technology to cope with multiple working conditions.

Product Core Competitiveness

1. The dump truck has been verified by the industry's longest reliability test mileage of 1.5 million kilometers.

2. The truck chassis is equipped with EBS, ESC and optional hydraulic retarder as standard.

3. Fuel consumption per 100 kilometers: 25.5L (specific working conditions).

4. The front of the dump truck comes standard with a wide sleeper 920mm, wide rear window, four-point suspension cab, LED light source, and USB power supply.

5. The truck is equipped with multi-function steering wheel and Bluetooth function.

detail of dump truck.jpg

Specification

Wheel base   (mm)

3800+1450

Overall Dimension

8500X2500X3484

Max loading

40000kg

Curb weight (kg)

12300

Front overhang/rear overhang (mm)

1410/1870

Approach angle/Departure angle

26/33

Max Speed:(Km/h)

≤85km/h









Engine  (WEICHAI)



Model

WP10.340E32,water-cooled,four strokes,6 cylinders straight in line,turbocharged,

Fuel type

Diesel

Min rate of consuming fuel(g/(kw.h))



198g/kw.h

Rated Power / rotating

(kw/(r/min)



250Kw/2200rpm(340HP)

Emission

EURO III EGR

Maximum Torque / rotating speed(n.m/(r/min)



1350Nm/1100-1600rpm

Displacement(ml)

9726

Fuel tanker capacity (L)

400L Iron

Clutch

Model

#430, Single dry frictional disc,Hydraulic boosting

Gearbox

Model



FAST  9JS150A  mechanical type,mechanical type,Based on Fuller Eaton technology , 9 Forward speed gear,1 reverse gear.



<span style=";

Service brake



Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system



Model



Z15, whole circulation in ball type, hydraulic boosting

Suspension System



Front Suspension



Non-free standing leaf spring,telescopic shock absorber with stabilizer bar suspension,10pcs springs

Middle & Rear Suspension

Non-free standing stabilization spring, stabilization suspension,13pcs springs

Frame



Fish belly shape, variable width, variable sections

(Benz Technology)

Cross section dimension of

frame(mm)

317x70x8.5+7+8mm

Front axle (Mercedes Benz Technology)



Double-shoe pneumatic brake, 7.5 tons no-driving steering axle

Middle and Rear axle (Mercedes Benz Technology)



Double-shoe pneumatic brake, ductile casting casing, with hub redactor, 13 tons double reduction driving axle,speed ratio 5.263

Middle axle: HD7/016DGS-13/5.263

Rear axle: HL7/015DS-13/5.263

Tire

12.00R20  radial tire

Qty of tire

11(10+1)

Electrical system



Battery

2X12V/135Ah

Generator

28V-70A

Starter

5.58Kw/24V

Cab



NG80B right hand drive

Short cab without sleeper

Full steel skeleton structure, covered with double layer steel plate;

Can be tipped forwardly;

Interior trimming:

Integral interior trimming, Integral instrument, digital instrument, radio (with USB interface+MP3), high back/shock absorption seat for driver, high back seat for co-driver. Steering wheel can be adjusted. With inner A/C。

Exterior trimming:

Metal bumper, three steps, new mirror.



Other specifications



Two stage air filter, 76°Tropical thermostat

Tipper Body (Optional)



Dimension:5600x2300x1500=19m3, Bottom 8mm, Side 6mm,  HYVA Front lifting system,manganese plate.

Product Image

dump truck.jpg

Dump truck packaging and transportation

dump truck12.jpg

We take naked and waxed and ship by bulk carrier, flat deck or RO-RO.

(1) Wax

The truck body is wax-sprayed during transport to expose it to seawater corrosion.

(2) Packaging

Secure with steel wire to protect the truck during transportation.

(3) Shipping

Reliable logistics services from well-known freight suppliers make the transportation process safe and timely.

Successful case

dump truck success case.jpg

We have many years of truck sales experience, and our products are sold to more than 1,000 customers in more than 50 countries and regions such as the Philippines, Ethiopia, Indonesia, and Russia.

The services we can provide are:

1. Respond to your inquiry within 12 working hours;

2. Experienced staff to answer all your questions;

3. The customer's design can be used for some products (OEM);

4. All kinds of engine mechanical parts with reasonable price;

5 Different kinds of semi-trailers can offer competitive prices.

6. We also provide spare parts (original, OEM and replacement) for all types of trucks and trailers with high quality to ensure trucks and trailers are in good working condition.
